The Ejectors
Quickly extract frozen food blocks from the Beck
Freezing Frames in a safe manner.
- Item number: 75-1 with chute/slide
- Dimensions: 60*80*180mm
- Capacity: 6-8 pieces / minute
- Air required: 55 liters (14.5gallons) per block ejected at 6bar (90psi)
The details
Ejection
The Beck Block Ejector uses metal pistons to push
the frozen food block out of the Beck Freezer Frame.
Type 75-1 is the most sold manual ejector.
The slide is covered with a PE sheet to make the
block slide down easily. A rubber sheet dampens the
impact between block and ejector and protects both
from damages.
Advice
Leave blocks to rest 8-10 minutes after freezer be-
fore ejecting to avoid running at high pressure (lead-
ing to marks from pistons) and damaging Beck Liner
protecting the food block. Leaving blocks to rest for
8-10 minutes will reduce stress between frozen food
block and freezing frame and lead to perfectly eject-
ed blocks.
We have used Beck liners for 15 years and today they still deliver the best product on the market”
Client Survey 2023
Other ejectors available
Pneumatic block ejector with chute/slide and bucket
Type 75-3 Item no. 41120
| Dimension | 60*80*180cm |
| Capactity | 6-8 blocks per minute |
| Air required | 55 liters (14.5gallons) per block ejected at 6bar (90psi) |
| Feature | Bucket suitable for master carton |
Pneumatic block ejector with conveyor
Type 75-2 Item no. 41131
| Dimension | 60*135*180cm |
| Capactity | 6-8 blocks per minute |
| Air required | 55 liters (14.5gallons) per block ejected at 6bar (90psi) |
| Feature | Adjustable conveyor height: 650-800mm |
Automatic ejector with conveyor
Type 75-2-a Item no. 41150
| Dimension | 200*90*210cm |
| Capactity | 10 blocks per minute |
| Air required | 55 liters (14.5gallons) per block ejected at 6bar (90psi) |
| Feature | Designed for in-line automatic extraction of blocks |
Pneumatic double ejector with chute/slide
Type 77-1 Item no. 42110
| Dimension | 180*80*125cm |
| Capactity | 12-16 blocks per minute |
| Air required | 55 liters (14.5gallons) per block ejected at 6bar (90psi) |
| Feature | Suitable for Beck double freezing frames |
Certificates
ISO 9001
ISO 22000
FSSC 22000
Most asked questions
Who do I contact for an order?
Please don’t hesitate reaching out using our contact form
How do I use the Beck Liner?
Please download our Block Manual – HERE
Can the Beck Liner be recycled?
YES – at Beck we have started a recycling program together with FERMACELL for the used liners. For more information please don’t hesitate to contact us.
What is Beck Liner made from?
The Beck Liner consists of our own unique recipe for both cardboard and wax. The cardboard is made of 100% recycled fibers – for more information please download our specification sheet – HERE
Beck-liner
| Available sizes | Standard size 481*253*60mm Custom liner upon request |
| Printing | We offer a number of standard prints, as well as custom printing on top and bottom of the liner, fx. logo, text, check boxes etc. Colours: 1 colour prints |
Call us
Our sales team are ready to take your call and to make sure you get the right liner for your need.
Phones open
Monday – Friday
8.00AM – 4PM (GMT+1)
Contact us
Fill out the form to get contacted within 24 hours
The Beck Liner™ goes with
Beck Spareparts
All ejector spareparts are available upon request
Beck Frame Straightener
Secures high quality
Freezing frames lose correct dimension over time as
they are metal fatigued. That is why you need to check and make sure your frames hold the right dimensions.
Beck Measuring Board
Quality check
Ensure freezing frames are up to date using The Beck
Measure board on regular basis.
By ensuring your freezing frames and bottoms are
of good quality you also ensure good quality of your
final block.
Beck Frame
The perfect fit between liner and frame
Aluminium freezing frames that enable an efficient filling and freezing of the food blocks.
Beck Trolley
The Beck trolley is designed for easy and correct intermediate storage and transport of the Beck Freezing Frame in combination with the 16.5lbs/7.5kg Beck Carepack Liner.
Beck Liner
It is designed for optimal processing time and minimal waste, and makes the packing and stripping process easy and ensure the flattest block surfaces possible.
Paper consisting of 100% recycled cellulose fibers.
